Here are some Hints and Tips on how to plumb and connect our breather tanks for maximum performance and efficiency. Remote breather tanks eliminate any possibility of oil residue on your valve covers or exhaust while capturing and isolating residual liquid vapor from escape with hi volume engines. PCV configurations are best to prolong oil life, reduce contamination and promote engine sealing when there is vacuum and the open breather system is a last resort or when running wide open throttle for most of the engine's operating cycle.

CHECK OUT OUR BILLET ALUMINUM  BREATHERS  (click above)

BREATHERS
WITH PCV
VALVES
REMOVED

EXPLANATION: Crankcase pressures exit engine through the opened breathers in the valvecovers through hoses to the breather tanks

The breather tanks prevent oil vapor from escaping and is baffled off where any accumulation can be periodically drained away.

BREATHER
WITH PCV
VALVE
REMOVED

BREATHER
WITH HIDDEN
PCV VALVE
INSTALLED
(routed to vacuum port)

PCV CONNECTED
TO VACUUM FROM INTAKE MANIFOLD
PLENUM UNDER THE CARBURETOR

EXPLANATION: Fresh air is pulled in through the breather tank and hoses into the opened valve cover breather and into the engine.

Then the contaminants in the crank case are pulled through the PCV breather and into the intake vacuum which is burned in the engine.

BREATHERS
WITH PCV
VALVES
REMOVED

(routed to vacuum port)

EXPLANATION: Fresh air is pulled in through the breather tanks and hoses into the opened valve cover breathers and into the engine.

Then the contaminants in the crank case are pulled through the PCV breather and into the intake vacuum which is burned in the engine.

PCV BREATHER INSERTED INTO BASE OF IN INTAKE MANIFOLD TO PULL AIR FROM THE LIFTER VALLEY
PCV HOSE CONNECTED TO VACUUM FROM INTAKE MANIFOLD PLENUM UNDER THE CARBURETOR
